A2 Grade FR Aluminum Corrugated Panel Sandwich Board 1220/1250/1500MM
The core board of the corrugated board is a water corrugated type, which forms an air channel between the front panel and the back panel. It is a hollow board system and is the best product for thermal insulation. Under the action of solar radiation, the air in the channel heats up and flows upward to take away heat, which has thermal insulation properties.
In cold areas, the upper and lower ends of the corrugated channel are sealed, and under the sunlight during the day, heat energy is stored to reduce the loss of indoor heating heat, and it has thermal insulation performance.
The remaining materials in the project can be recycled by 100%, which is environmentally friendly and pollution-free.
| Specifications Of Aluminum Corrugated Panel |
| |
| Width | 1220mm, 1250mm, 1500mm(maxium) |
| Length | Up to 5800mm. |
| Total Panel Thickness | 4-6mm |
| Aluminum Alloy | AA1100,AA3003,AA5005 ...(Other Grade On Requirement) |
| Skin Thickness | 0.4mm to 2mm |
| Surface Teatment | PE coating , PVDF coating, FEVE coating |
| Color | Metal color, matte color, high glossy color, nano, brushed, granite and wooden etc |
| Core | Solid non-combustible aluminum corrugation core |
| Fire Retradant Grade | A2 Grade |
| MOQ | 500 Sqm per color |
| Weight | 3.5-6KG/SQM |
| MEMO | Non-standard sizes and special colors can be customized according to customers’ offers. |
FAQ
Q1. What is the minimum order quantity?
500Sq M for aluminium composite panel for one color with 1220 mm*2440 mm size.
Q2. What is your terms of payment?
T/T 30% deposit in advance; the balance should be paid according to the copy of B/L.
Q3. How about your delivery time?
Generally, it will take 15to 20days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Can you produce according to the samples?
Yes, we can produce by your samples or technical drawings.
Q5. Why can I trust you and place order with you?
1. We are manufacture and supplier of aluminum composite panel in china with over 10 years's experience.
2. We keep fastest delivery. Since we have perfect production equipment.
Product Tags:
|
|
A2 FR Grade Aluminum Corrugated Panel 1500mm Aluminium Sandwich Board Images
|
